Tektronix DPO5054B 混合信号示波器

DPO5054B是Tektronix（泰克）公司生产的一款混合信号示波器。以下是关于DPO5054B的一些主要特点和技术规格：

1. 带宽和采样率：DPO5054B提供高达500MHz的带宽，以及所有通道上高达5GS/s的采样率。这使得它能够准确地捕获和分析高速信号。
2. 分析能力和数学运算功能：DPO5054B具有很强的分析能力和数学运算功能，可以简化和加速复杂和混合信号设计的调试，并有助于捕获其他示波器经常遗漏的间歇性事件。
3. 波形捕获和显示：泰克专有的FastAcq®技术提供快速波形捕获，每秒超过250,000个波形，使您能够在几秒钟内看到毛刺和其他不常见的瞬变，揭示设备故障的真实性质。MultiView Zoom™技术允许用户同时查看多个信号或信号的不同部分，而FastFrame®分段存储器采集模式则可以捕获长时间段的信号，同时保持高捕获速率。
4. 探头和连接性：DPO5054B标配10MΩ无源电压探头，提供了<4pF电容负荷及500MHz或1GHz模拟带宽。此外，它还可以与泰克的各种探头和附件配合使用，以扩展其测量能力。
5. 用户界面和软件：DPO5054B具有直观的用户界面和强大的软件功能，如Wave Inspector®控件，使用户能够轻松导航、注释和导出测量结果。它还可以运行基于Windows的分析软件，以进一步扩展其功能。
6. 应用领域：DPO5054B适用于各种领域，包括通信、半导体、航空航天、汽车电子、消费电子等，用于调试和分析复杂的信号和系统。

总的来说，DPO5054B是一款功能强大、性能卓越的混合信号示波器，能够满足各种高速信号测量和分析的需求。

DPO5054B is a mixed signal oscilloscope produced by Tektronix. The following are some main features and technical specifications of DPO5054B:

Bandwidth and sampling rate: DPO5054B provides a bandwidth of up to 500MHz and a sampling rate of up to 5GS/s on all channels. This enables it to accurately capture and analyze high-speed signals.
Analytical ability and mathematical operation function: DPO5054B has strong analytical ability and mathematical operation function, which can simplify and accelerate the debugging of complex and mixed signal design, and help capture intermittent events often missed by other oscilloscopes.
Waveform capture and display: Tech’s proprietary FastAcq ® The technology provides fast waveform capture, with over 250000 waveforms per second, allowing you to see spikes and other uncommon transients within seconds, revealing the true nature of equipment failures. MultiView Zoom ™ Technology allows users to view multiple signals or different parts of a signal simultaneously, while FastFrame ® The segmented memory acquisition mode can capture signals for a long period of time while maintaining a high capture rate.
Probe and connectivity: DPO5054B comes standard with a 10M Ω passive voltage probe, providing<4pF capacitive load and 500MHz or 1GHz analog bandwidth. In addition, it can also be used in conjunction with various probes and accessories of Tech to expand its measurement capabilities.
User interface and software: DPO5054B has an intuitive user interface and powerful software features, such as Wave Inspector ® Control, allowing users to easily navigate, annotate, and export measurement results. It can also run Windows based analysis software to further expand its functionality.
Application areas: DPO5054B is suitable for various fields, including communication, semiconductor, aerospace, automotive electronics, consumer electronics, etc., used for debugging and analyzing complex signals and systems.
Overall, DPO5054B is a powerful and high-performance mixed signal oscilloscope that can meet various high-speed signal measurement and analysis needs.
