GE Fanuc IC693CPU374

The GE Fanuc IC693CPU374 Single Slot CPU Module is a versatile and powerful component for industrial automation systems. Below is a detailed overview of its features and specifications:

Overview

• Manufacturer: GE Fanuc
• Model: IC693CPU374
• Type: Single Slot CPU Module

Processor

• Processor Speed: 133 MHz
• Architecture: AMD SC250
• Typical Scan Rate: 0.15 milliseconds per 1K boolean logic

Memory

• Total User Memory: 240 KB

• Configurable Memory Types:

  • Register Memory (%R)
  • Analog Input (%AI)
  • Analog Output (%AO)
  • Each of these memory types can be configured with a storage capacity ranging from 128 to approximately 32,640 words.

Communication

• Ethernet Ports: Two ports with auto-sensing capabilities
  • Supported Speeds: 10/100 Mbps
  • Protocols Supported: SRTP, Ethernet Global Data, Modbus/TCP client/server
• RS-485 Port: Supports SNP and SNPX protocols when powered through this port.

Power and Environment

• Power Requirements: 7.4 watts, supplied by 5V DC voltage
• Operating Temperature Range: 0°C to 60°C
• Storage Temperature Range: -40°C to 85°C (when not in use)

Additional Features

• System Expansion:

  • The module comes with eight chassis slots, including one CPU chassis and seven expansion or remote chassis.
  • It is compatible with programmable communication coprocessors.

• Fixed Points and Storage:

  • 2048 fixed discrete input and output points
  • 1280 bits of discrete global storage capacity

• Registers:

  • Contains 28 fixed system registers with timers and counters.

• Battery Backup: The CPU module is powered by a battery, which supplies power to the system clock and RAM.

• Programming and Configuration:

  • Supports different programming languages.
  • Can process floating-point data.
  • Can be configured using VersaPro or CIMPLICITY machine edition logic software.

Applications

The IC693CPU374 module is designed for use in industrial automation systems, where it can host user programs, execute logic, and manage data exchange through its embedded communication ports. It is suitable for applications requiring high processing power and reliable communication capabilities.

In summary, the GE Fanuc IC693CPU374 Single Slot CPU Module is a robust and versatile component that offers advanced processing capabilities, ample memory, and flexible communication options. Its compact design and expandability make it ideal for a wide range of industrial automation applications.
