NI PXIE-5105

Description

PXIE-5105是一款高性能的数字化仪，适用于各种数据采集和信号处理应用。它具备以下主要特点：

1. 多通道同步采样：PXIE-5105提供8路同步采样通道，这意味着可以同时采集多个信号，保证数据之间的时序一致性，这对于需要精确时间相关性的测量尤为重要。
2. 高垂直分辨率：该设备具有12位的垂直分辨率，这允许设备对输入信号进行精细的量化，从而能够捕捉到更微小的信号变化。
3. 高采样率和带宽：实时采样率高达60MS/s，模拟带宽为60MHz，使其能够准确地捕获高速和宽带宽的信号。
4. 灵活的信号设置：PXIE-5105提供了灵活的耦合、阻抗、电压范围和滤波设置，用户可以根据需要调整这些参数，以适应不同类型的信号。
5. 多种触发模式：用户可以根据不同的触发条件捕获特定的信号事件，提高测量的准确性和精度。
6. 高级PXI同步和数据流功能：支持高级PXI同步和数据流功能，有助于在多设备系统中实现精确的同步和数据传输。
7. 仪器驱动和数据流：包括一个仪器驱动，支持数据流和数据分析功能，使用户能够更方便地处理和分析采集到的数据。The PXIE-5105 is a high-performance digitizer for a variety of data acquisition and signal processing applications. It has the following main features:

   Multi-channel synchronous sampling: The PXIE-5105 provides 8 channels of synchronous sampling, which means that multiple signals can be collected at the same time to ensure timing consistency between data, which is particularly important for measurements requiring accurate time correlation.
   High vertical resolution: The device has a vertical resolution of 12 bits, which allows the device to perform fine quantification of the input signal, enabling it to capture even smaller signal changes.
   High sampling rate and bandwidth: real-time sampling rate up to 60MS/s, analog bandwidth of 60MHz, enabling accurate capture of high-speed and wide-band signals.
   Flexible signal Settings: The PXIE-5105 offers flexible coupling, impedance, voltage range, and filter Settings that users can adjust as needed to accommodate different types of signals.
   Multiple trigger modes: Users can capture specific signal events according to different trigger conditions, improving the accuracy and precision of measurement.
   Advanced PXI Synchronization and data Streaming capabilities: Support for advanced PXI synchronization and data streaming capabilities helps achieve accurate synchronization and data transfer in multi-device systems.
   Instrument Driver and Data Flow: Includes an instrument driver that supports data flow and data analysis functions to make it easier for users to process and analyze collected data.
