ABB CI871K01 3BSE056797R1

Description

CI871K01 3BSE056797R1是一款功能强大的通信接口模块，它具有多种特性和广泛的应用领域。

首先，CI871K01 3BSE056797R1模块支持高速通信，可以在10 Mbps和100 Mbps之间进行选择，这定义在IEEE 802.3u 10/100 Base-Tx标准中。这种高速通信能力使得它能够处理大量的数据交换，满足各种复杂的通信需求。

其次，该模块具有状态指示灯，可以直观地显示其运行状态。当运行正常时，指示灯为绿色；如果出现异常故障，指示灯会变为红色。此外，还有两个交通指示灯（RxTx1和RxTx2），用于指示通信状态，从而方便用户进行故障排查和系统监控。

在电源和功耗方面，CI871K01 3BSE056797R1模块通过CEX总线接收24VDC的电源，其电流消耗最大为250 mA。在典型工作条件下，功耗为3.8 W，最大功耗为6 W，这使得它在各种应用场景下都能保持高效且稳定的运行。

此外，该模块还具备一定的防尘和防水能力，但不适用于恶劣的工业环境。在尺寸和重量方面，它的尺寸为59 x 185 x 127.5毫米（2.9 x 7.3 x 5.0英寸），重量为500克（带包装时为700克），这使得它在安装和布局方面具有较大的灵活性。

CI871K01 3BSE056797R1 is a powerful communication interface module with a variety of features and a wide range of applications.

First, the CI871K01 3BSE056797R1 module supports high-speed communication and can choose between 10 Mbps and 100 Mbps, as defined in the IEEE 802.3u 10/100 Base-Tx standard. This high-speed communication capability enables it to handle a large amount of data exchange and meet a variety of complex communication needs.

Secondly, the module has a status indicator that can visually show its operating status. When the operation is normal, the indicator is green. If an abnormal fault occurs, the indicator will turn red. In addition, there are two traffic lights (RxTx1 and RxTx2) to indicate the status of communication, which facilitates troubleshooting and system monitoring.

In terms of power and power consumption, the CI871K01 3BSE056797R1 module receives 24VDC power through the CEX bus and its current consumption is up to 250 mA. Under typical operating conditions, the power consumption is 3.8W and the maximum power consumption is 6W, which makes it efficient and stable in a variety of application scenarios.

In addition, the module also has some dust and water resistance, but is not suitable for harsh industrial environments. In terms of size and weight, it measures 59 x 185 x 127.5 mm (2.9 x 7.3 x 5.0 inches) and weighs 500 grams (700 grams with packaging), which gives it greater flexibility in terms of installation and layout.
