ABB IGCT 5SHX2645L0002

Description

5SHX2645L0002是一款由ABB公司推出的中压电力电子开关器件模块，它集成了门极可关断晶闸管（GTO）芯片、反并联二极管和门极驱动电路。这款模块具有高效、稳定的控制特性，是电力系统中的重要组件。

该模块结合了晶闸管的高电流处理能力和IGBT的快速开关能力，使得它在高电压、大电流控制应用中表现出色。它的门极驱动器与外部电路的连接经过优化，以减小电感并提高性能。此外，5SHX2645L0002模块还采用了紧凑的结构设计，易于安装和维护。

在技术参数方面，5SHX2645L0002模块的额定电压为4500V，额定电流为2600A，最大电压可达6000V，最大电流为3900A，开关速度高达1μs。这使得它能够满足各种高要求的电力控制任务。

该模块在直流调速中压板应用中也表现出色，易于控制，可靠性高。此外，它还可以应用于带或不带失谐电抗器的电容器单元，实现高速切换，并监测电源电压、输入触发器和热故障等。

The 5SHX2645L0002 is a medium voltage power electronic switching device module from ABB that integrates a GTO chip, an anti-parallel diode and a gate drive circuit. This module has efficient and stable control characteristics and is an important component in power systems.

The module combines the high current processing capability of thyristors with the fast switching capability of IGBTs, making it excellent in high voltage and high current control applications. The connection of its gate driver to the external circuit is optimized to reduce inductance and improve performance. In addition, the 5SHX2645L0002 module features a compact design that makes it easy to install and maintain.

In terms of technical parameters, the 5SHX2645L0002 module has a rated voltage of 4500V, a rated current of 2600A, a maximum voltage of 6000V, a maximum current of 3900A, and a switching speed of up to 1μs. This enables it to meet a variety of demanding power control tasks.

The module also performs well in DC speed regulating medium plate applications, easy to control and high reliability. In addition, it can be applied to capacitor units with or without a detuned reactor, enabling high-speed switching, and monitoring power supply voltages, input triggers, and thermal failures.
