IS215UCVEH2AE+TPMC815-11 1S215UCVEM08B

IS215UCVEH2AE+TPMC815-11=IS215UCVEM08B是通用电气（GE）生产的一种数字输入/输出模块。

其中，IS215UCVEH2AE是通用电气公司Mark VI Speedtronic控制系统的一个组件，其功能是作为VME控制卡。VME卡架是Mark VI的标准架，有13或21槽架可供选择。该板包括板体内的垂直引脚连接器和沿板边缘的直角引脚连接器，同时还有几个集成电路、电阻、电容、扼流圈等元件。此外，有一个小电路板以一定角度安装在电路板的中心，散热器盖位于电路板的一半以上。

TPMC815-11则是一个与IS215UCVEH2AE配合使用的模块，它们组合后形成了IS215UCVEM08B数字输入/输出模块。该模块具有8点数字输入和8点数字输出，电压为24伏特，功耗为1.2瓦特。它的工作温度为-40至70摄氏度，存储温度为-40至85摄氏度，相对湿度为5%至95%非凝结，防护等级为IP20。

IS215UCVEM08B模块的主要功能是实现数字信号的输入和输出功能，将外部数字信号转换为PLC或DCS可读取的信号，同时，也能将PLC或DCS的信号转换为数字输出信号。这使得它能够与PLC或DCS系统进行无缝通信和控制，适应各种不同类型的自动化控制系统需求。

IS215UCVEH2AE+TPMC815-11=IS215UCVEM08B is a digital input/output module manufactured by General Electric (GE).

The IS215UCVEH2AE is a component of General Electric’s Mark VI Speedtronic control system that functions as a VME control card. The VME bracket is standard for Mark VI and is available in 13 or 21 slots. The board includes a vertical pin connector in the body of the board and a right Angle pin connector along the edge of the board, and several integrated circuits, resistors, capacitors, chokes and other components. In addition, there is a small circuit board mounted at an Angle in the center of the circuit board, and the radiator cover is located more than half of the circuit board.

TPMC815-11 is a module used in conjunction with the IS215UCVEH2AE, which is combined to form the IS215UCVEM08B digital input/output module. The module has an 8-point digital input and 8-point digital output with a voltage of 24 volts and a power consumption of 1.2 watts. It has an operating temperature of -40 to 70 degrees Celsius, a storage temperature of -40 to 85 degrees Celsius, a relative humidity of 5% to 95% non-condensing, and a protection class of IP20.

The main function of IS215UCVEM08B module is to realize the input and output functions of digital signals, convert external digital signals into signals that can be read by PLC or DCS, and at the same time, convert PLC or DCS signals into digital output signals. This enables it to communicate and control seamlessly with PLC or DCS systems, adapting to the needs of various types of automated control systems.
